Removing the Fabric Interconnect F1-15 Front Panel Assembly
FIGURE 97
Remove a Fabric Interconnect F1-4 Front Panel
Assembly
To remove a Fabric Interconnect F1-4 front panel assembly, you will need a #2 Phillips-head
screwdriver.
To remove a Fabric Interconnect F1-4 front panel, follow this procedure:
1.
Power down the Fabric Interconnect.
2.
Using the screwdriver, release the two spring-loaded screws (1) that secure the
release levers to the front mounting brackets. See
Fabric Interconnect F1-4 Front Panel Assembly," on page
Remove a Fabric Interconnect F1-4 Front Panel Assembly
Figure 98, "Removing the
154.
Performing Service Tasks
153
