Understanding Chassis Components and Indicators
QDR Fabric Interconnect F1-4 Rear Panel Components
FIGURE 33
Fabric Interconnect Control Panel
The Fabric Interconnect control panel contains LEDs that provide indicators of the system's
status as well as a power LED and power button for hard power on and off.
Figure 34, "Fabric Interconnect F1-15 Control Panel," on page 61
shows the Fabric
Interconnect control panel on a Fabric Interconnect F1-15. The Control Panel is on the front of
the Fabric Interconnect F1-15 chassis.
FIGURE 34
Fabric Interconnect F1-15 Control Panel
Installing the Fabric Interconnect
61
