Remove Fabric Interconnect F1-4 Power Supplies
Note -
might jostle in the cable tie. When reconnecting power cords after servicing the power supplies,
make sure read the requirements documented in
Unplug the power supply that needs to be removed.
1.
Grasp the PSU handle with one or more fingers so that your thumb rests on the
2.
locking tab, shown in
page
3. Simultaneously, press the locking tab to the right (1) and pull the PSU out of
the Fabric Interconnect F1-4 (2) as shown in
Interconnect F1-4 PSU," on page
While sliding the power supply out of the chassis, you will need to hold the locking tab in long
enough to allow the locking pins on the side of the power supply to clear the chassis' sheet
metal.
FIGURE 67 Removing a Fabric Interconnect F1-4 PSU
Note -
110 Oracle Fabric Interconnect Hardware User's Guide • July 2016
When removing Fabric Interconnect F1-4 power supplies, be aware that the power cords
Figure 67, "Removing a Fabric Interconnect F1-4 PSU," on
110.
Both PSUs are oriented in the same direction, so both locking tabs pull to the right.
"Power Cord Management" on page
Figure 67, "Removing a Fabric
110.
46.
