httpproxy-port
phone-home-frequency
-------------------------------------------------------------------------------
1 record displayed
In this example, the bold text highlights the current state of the ID LED. True indicates that the
LED is on (illuminated), and false indicates that the LED is off (dark).
5.
If the LED is on (the locator-led-on parameter shows true), deactivate it when the
service call is completed. For example:
set system id-led off
Removing Fan Modules
This section documents how to remove and install a fan module. You can do this procedure
on one fan module at a time without powering down the Fabric Interconnect. To remove fan
modules, you will need a #2 Phillips (cross-head) screwdriver.
Caution -
overtighten screws or they can break.
Caution -
out of its shipping package or not in the Fabric Interconnect chassis, make sure you place it in
an ESD safe bag or on a grounded work surface such as a rubberized work mat.
See the appropriate section:
"Remove Fabric Interconnect F1-15 Fan Modules" on page 103
■
"Remove Fabric Interconnect F1-4 Fan Modules" on page 105
■
Remove Fabric Interconnect F1-15 Fan Modules
Fabric Interconnect F1-15 fan modules are located on the front of the chassis.
To remove and install a Fabric Interconnect F1-15 fan module, follow this procedure:
1.
Use a Phillips screwdriver to release the two spring-loaded securing screws
located at the right edge of each fan module. See
Fabric Interconnect F1-15 Fan's Securing Screws," on page
3128
weekly
When tightening screws, make sure to tighten them to lightly snug. Do not
When replacing the Fan Modules: - wear an ESD wrist strap - When the hardware is
Removing Fan Modules
Figure 61, "Releasing the
104.
Performing Service Tasks
103
