Note -
space becomes available.
5.
Install I/O modules as documented in
As an option, you can install the cable management assembly (CMA).
6.
If you want to install the CMA, see
Assembly" on page
Installing the Cable Management Assembly
The cable management assembly shipped with the Fabric Interconnect F1-15 is the standard
CMA used in Oracle 4-post equipment racks. The CMA consists of the following parts:
two stand-off brackets, which attach to the equipment rack.
■
the comb, which is a crenelated metal piece that has "slots" in which cables rest. This piece
■
attaches to the two stand-off brackets.
the plate, which is a flat metal piece that covers the top of the "slots" in the comb so that
■
cables cannot be accidentally lifted out of the slots in the comb.
screws of different types (M6, 10-32, or 12-24) that match with many common types of
■
equipment rack. Be aware that racks can be either tapped or not. If the rack is not tapped,
to install the CMA, you will need to use either cage nuts with the M6 screws, or locking
washers with the 12-24 screws
Note -
the stand-off brackets for the CMA will prevent the rack-mount brackets for the Fabric
Interconnect chassis form being installed. Make sure to install the Fabric Interconnect
completely before attempting to install the CMA.
Required Equipment
For this procedure, you will need the following equipment:
#2 Phillips (cross-head) screwdriver
■
Marker or tape to indicate a level plane on which the stand-off brackets will be installed
■
Four (4) M6 cage nuts
■
Four (4) M6 x 16 mm screws
■
It is not mandatory to remove the rail kit, but if you do, an extra 1U of vertical rack
37.
The CMA must be installed after the Fabric Interconnect is installed because
Installing the Cable Management Assembly
"Installing an I/O Module" on page
"Installing the Cable Management
Installing the Fabric Interconnect
69.
37
