Installing the Fabric Interconnect F1-4 in a 4-Post Rack
Caution -
AC power disconnect. As a result, the facility power socket outlet shall be installed near the
equipment and shall be easily accessible.

Required Equipment

For this procedure you will need:
#2 Phillips (cross-head) screwdriver
■
Marker or tape
■
Ruler or measuring tape.
■
Screws for Fabric Interconnect bracket mounting. The screws come in a large bag. The large
■
bag contains fourteen (14) M3.5 x .6 x 6 mm Phillips countersink screws for attaching the
rack-depth measures and optional cable management brackets.
Screws for Fabric Interconnect rack install. The screws come in a large bag that contains 3
■
smaller bags for different types of common equipment racks:
■
■
■
■
■
Note -
allow successful installation in a wide variety of common equipment racks. You will use
only the bag of screws that is appropriate for type of rack in which you are installing the
Fabric Interconnect.
Oracle rack mounting hardware:
■
■
■

Pre-Installation Considerations

Be aware of the following considerations before beginning the installation procedure.
You will find it helpful to determine the depth of the rack to know where to attach the side
■
panels to the chassis.
48 Oracle Fabric Interconnect Hardware User's Guide • July 2016
For the Fabric Interconnect F1-4 only, input power cords are used as the main
Eight (8) 10-32 x .75" Phillips pan-head screws
Eight (8) 12-24 x .75" Phillips pan-head screws
Eight (8) #12 lock washers
Sixteen (16) M6 x 20 mm Phillips pan-head screws
Sixteen (16) M6 cage nuts, EIA rack, M6/BL2, 5/9x9
You do not need all 3 bags of screws. The different bags of screws are supplied to
Rack-depth measures
Right angle brackets
