When the Front Panel is inserted into a Fabric Interconnect F1-4, the Fabric Interconnect
■
remains powered down until you physically press the Power button on the Front Panel.
(For information about powering on the Fabric Interconnect F1-15, see
Interconnect F1-4 Front Panel Assembly" on page
the Fabric Interconnect do not take affect. Instead, you must press the Power button.
Due to the different form factor between the Fabric Interconnect F1-15 and Fabric Interconnect
F1-4, some hardware elements are not interchangeable between the Fabric Interconnect F1-15
and Fabric Interconnect F1-4:
Front Panel
■
PSUs
■
Fans
■
Management Module
■

The ID LED

The ID indicator LED (ID LED) on the Fabric Interconnect front panel provides a visual
indicator of the Fabric Interconnect if it needs service. You can turn on the ID LED to allow a
Oracle-certified technician to find the Fabric Interconnect that needs service. See
Button and ID LED Location," on page
FIGURE 60

Activate and Deactivate the ID LED

Note -
Fabric Interconnect Front Panel," on page
The ID LED can be controlled through software or through the ID button. To activate the ID
LED, follow this procedure:
ID Button and ID LED Location
For information about the LED codes for the ID LED, see
153). Software command that restart
101.
69.
The ID LED
"Remove a Fabric
Figure 60, "ID
Figure 42, "LED Codes —
Performing Service Tasks 101
