Remove and Install a Fabric Interconnect F1-15 Front Panel Assembly
FIGURE 96
3.
Simultaneously grasp both of the release levers and slowly raise them until they
are horizontal (2), then use the levers to carefully slide the assembly out of the
chassis (3). See
Assembly," on page
152
Oracle Fabric Interconnect Hardware User's Guide • July 2016
Loosening the Fabric Interconnect F1-15 Front Panel Assembly Screws
Figure 97, "Removing the Fabric Interconnect F1-15 Front Panel
153.
