Remove Fabric Interconnect F1-4 I/O Modules
set vnic <vnic-name> -if=5/3
set vnic <vnic-name> -if=5/4
Removing and Inserting Fabric Interconnect F1-4
I/O Modules
The Fabric Interconnect F1-4 I/O Modules contain a locking mechanism (a quarter-turn Pawl)
that is built-in to the module's handle. The lock is used to secure the module in place while
it is inserted in the chassis, and has been designed with enough resistance that it cannot be
unlocked or completely locked with your fingers. As a result, the module's handle is slotted to
accept a screwdriver, which you will need to use to generate enough torque to lock or unlock
the module. To perform this procedure, you will need a large slotted screwdriver.
Caution -
dull or mar the slot in the I/O Module's handle. Also, if you apply excessive force, it might be
possible to over-rotate the handle, which will skew the I/O module's open and closed positions.
When using the screwdriver to lock or unlock an I/O Module, make sure to apply only enough
force to move the locking mechanism, and rotate the handle only enough to unlock or lock the
module.
The I/O module lock operates in a 90-degree arc, and the slot in the handle indicates the
position of the module's lock. See
positions for the locking I/O Modules.
Remove Fabric Interconnect F1-4 I/O Modules
When you are performing field replacement for one or more I/O Modules, make sure to use the
lock and unlocked positions appropriately—for example, make sure that you lock the modules
when you are done servicing them.
To remove a Fabric Interconnect F1-4 I/O module, follow this procedure:
1.
When handling I/O modules, make sure that you are using ESD safety
precautions, such as a grounding strap that is properly attached to an earth
ground source.
Before removing an I/O module, use the XgOS to shutdown the I/O module.
2.
3.
Using a slotted screwdriver, unlock the I/O module by turning it 90 degrees
counterclockwise. See (1) in
Module," on page
144
Oracle Fabric Interconnect Hardware User's Guide • July 2016
When using the screwdriver to lock or unlock an I/O Module, make sure not to
Table 1, "I/O Module Lock Positions," on page 70
Figure 93, "Removing a Fabric Interconnect F1-4 I/O
145.
