Communication
10.1 Communication according to PROFIdrive
Bit Meaning
Note:
When the motor temperature threshold is exceeded, only an alarm is output initially to warn you of this. The
•
alarm is canceled automatically when the temperature no longer exceeds the alarm threshold.
If the overtemperature is present for longer than the value set via p0606, a fault is output to warn you of this.
•
Motor temperature monitoring can be switched out via p0600 = 0.
•
Application:
The user can respond to this message by reducing the load. This prevents the motor from shutting down with the
"Motor temperature exceeded" fault after the set time has elapsed.
7 No thermal overload in power unit
alarm
8 Speed setp - act val deviation in
tolerance t_on
9 ESR response initiated / generator
operation active
10 Reserved
11 Controller enable
12 Drive ready
13 Pulses enabled
Application:
Armature short-circuit protection must only be switched on when the pulses are inhibited.
This signal can be evaluated as one of many conditions when armature short-circuit protection is activated.
14,15 Reserved
MELD_NAMUR
Display of the NAMUR message bit bar.
666
Remarks
1 No thermal overload in power unit alarm
The temperature of the heat sink in the power unit is
within the permissible range.
0 Thermal overload in power unit alarm
The temperature of the heat sink in the power unit is
outside the permissible range.
If the overtemperature remains, the drive switches
itself off after approx. 20 s.
1 The speed setpoint/actual value is within the
tolerance p2163: The signal is switched on after the
delay specified in p2167 has elapsed.
0 The speed setpoint/actual value is outside the
tolerance.
1 ESR response initiated
0 ESR response not initiated
- -
1 Controller enable
1 Drive ready
1 Pulses enabled
The pulses for activating the motor are enabled.
0 Pulses inhibited
- -
Function Manual, (FH1), 01/2013, 6SL3097-4AB00-0BP3
Parameter
BO: r2135.15
BO: r2199.4
r0887.12
-
BO: r0899.8
BO: r0899.7
BO: r0899.11
-
Drive functions
