Siemens SINAMICS S120 Function Manual page 109

Overview of important parameters (see SINAMICS S120/S150 List Manual)
• p0108.21
• p1656[0...n]
• p1657[0...n]
• p1658[0...n]
• p1659[0...n]
• p1660[0...n]
• p1661[0...n]
• p1662[0...n] to p1666[0...n]
• p1667[0...n] to p1671[0...n]
• p1672[0...n] to p1676[0...n]
• p1699
• p5200[0...n]
• p5201[0...n] to p5205[0...n]
• p5206[0...n] to p5210[0...n]
• p5211[0...n] to p5215[0...n]
• p5216[0...n] to p5220[0...n]
• p5221[0...n] to p5225[0...n]
• p5226[0...n] to p5230[0...n]
Parameterization with STARTER
The "Current Setpoint Filter" parameter screen is selected with the
the STARTER commissioning tool.
Drive functions
Function Manual, (FH1), 01/2013, 6SL3097-4AB00-0BP3
Drive objects, function module /
function module object 21
Current setpoint filters 1 to 4 activation
Current setpoint filter 1 type
Current setpoint filter 1 denominator natural frequency
Current setpoint filter 1 denominator damping
Current setpoint filter 1 numerator natural frequency
Current setpoint filter 1 numerator damping
Current setpoint filter 2 (for distribution see current
setpoint filter 1)
Current setpoint filter 3 (for distribution see current
setpoint filter 1)
Current setpoint filter 4 (for distribution see current
setpoint filter 1)
Filter data acceptance
Current setpoint filters 5 to 10 activation
Current setpoint filter 5 (for distribution see current
setpoint filter 1)
Current setpoint filter 6 (for distribution see current
setpoint filter 1)
Current setpoint filter 7 (for distribution see current
setpoint filter 1)
Current setpoint filter 8 (for distribution see current
setpoint filter 1)
Current setpoint filter 9 (for distribution see current
setpoint filter 1)
Current setpoint filter 10 (for distribution see current
setpoint filter 1)
Servo control
3.7 Current setpoint filters
icon in the toolbar of
