Step 2: Serial cables
Figure 48
Serial cables connect the Control Station to the CallHome modem.
To connect the serial cables:
1.
Figure 48
shows how to connect the preinstalled modem serial cable from the
CS 0 serial port to the first external modem. Then connect the modem to an
analog telephone line supplied by the customer.
Control Station
Serial connection from Control Station to modem
Connect Cables for a Direct-connected VG2
Modem
EMC CONFIDENTIAL
CIP-001139
Step 2: Serial cables
83
