Before Installing
Management module
Figure 18
Figure 19
44 EMC VNX VG2/VG8 Gateway Configuration Setup Guide
Each blade enclosure has two management modules. The two modules are redundant
for each enclosure. Figure 18
management modules A and B.
Control Station 1
Control Station 0
Management
module B
Management modules in a blade enclosure
The management module has three RJ-45 Ethernet ports (private LAN), one DB-9
(RS-232 serial port) connector, various LEDs, and a seven-segment display showing
the blade enclosure ID (Figure
2
Port 2
0
Port 0
RS-232 serial port
#
Management module
shows the rear view of a blade enclosure with
MODEM plug
CS
VGA socket
A
MODEM plug
CS
VGA socket
A
Management
module A
19).
1
Port 1
7-segment display
(blade enclosure ID)
CNS-001647
B MGMT
Serial
console
B MGMT
Serial
console
CNS-001656
