If you are using one switch to connect a CLARiiON CX3-80 array, connect the cables
as shown in
example, but you can use any two ports on each SP:
0 Fibre 1 Fibre
0 Fibre 1 Fibre
CLARiiON CX3-80 connected to a single switch
Figure 168
1. Connect SP A port 0 Fibre to the switch.
2. Connect SP B port 0 Fibre to the switch.
3. Connect SP A port 1 Fibre to the switch.
4. Connect SP B port 1 Fibre to the switch.
5. Record which SP ports you connected to which switch ports using the
cabling worksheet" on page
Note: If you did not use the default SP and FC switch cabling, you must manually select the FC
switch ports the array will use in
Cable Connections from Fibre Channel Switch to Storage
Figure 168. The CLARiiON array SAN ports 0 and 1 are used in this
273.
"Step 2: Install latest File OE on CS 0" on page
