VG2/VG8 Control
Station
Figure 9
Figure 10
VG2/VG8 CPU and
power supply/
cooling modules
Figure 11
Each VG2/VG8 system can have one or two Control Stations.
front view of the VG2/VG8 Control Station. Note the location of the power button
(also known as the reset button).
Control Station (front)
VG2/VG8 Control Station front view
Figure 10 shows the rear view of the VG2/VG8 Control Station. Note the location of
the serial console.
VG2/VG8 Control Station rear view
The VG2/VG8 blade enclosure can house two blades, and each blade is associated
with a CPU module (viewed from the front of the cabinet). Each blade CPU
(Figure 11) accommodates two power supply/cooling modules, which provide
power and cooling for the I/O modules that are associated with the blade.
Power supplies
1
1
CPU and power supply/cooling modules
Note: The VG2 provides only one blade enclosure, which usually contains two blades; if a
one-blade system is ordered, a CPU filler assembly occupies the location of the blade CPU. See
example in Figure 5 on page
Power button
Blade CPU
36.
EMC CONFIDENTIAL
Before Installing
Figure 9 shows the
CNS-000876
Serial port
CNS-000918
Blade enclosure
CNS-001636
Step 1: Check components 39
