If you are using one switch to connect a CX4-480 array, connect the cables as shown in
the example in
SP B
2
Figure 172 CX4-480 connected to a single switch (example)
The array SAN ports 2 and 3 are used in this example, but you can use any two ports
on each SP:
1. Connect SP A slot 0, port 2 to the switch.
2. Connect SP B slot 0, port 2 to the switch.
3. Connect SP A slot 0, port 3 to the switch.
4. Connect SP B slot 0, port 3 to the switch.
5. Record the SP ports you connected to the switch ports by using the
cabling worksheet" on page
Cable Connections from Fibre Channel Switch to Storage
Figure 172.
SP A
3 3 3
2 2
1 1
0 0
4
273.
EMC CONFIDENTIAL
Switch
1
CNS-000892
Connecting a CLARiiON CX4-480 array
