Manually Zone Switches and Configure System LUNs
Navisphere CLI
Example:
248 EMC VNX VG2/VG8 Gateway Configuration Setup Guide
If you are using Navisphere CLI, enter the following commands to register the blade
ports:
Note: If you are using different ports, change the SP port values.
The -type is 32 for R30 code and higher (the value for pre-R30 code is 3).
The recommended <storage_group_name> is the CS 0 hostname, Celerra_<hostname>Cs0 (for
example, Celerra_RTP55Cs0).
1. For a single switch enter the following:
#
navicli -h <SP_A_IP_address> storagegroup
-setpath -o -gname <storage_group_name>
-hbauid <blade_port_0_WWN>
-sp a -spport 0 –type 32 –failovermode 0 –arraycommpath 0
#
navicli -h <SP_A_IP_address> storagegroup
-setpath -o -gname <storage_group_name>
-hbauid <blade_port_0_WWN>
-sp b -spport 0 –type 32 –failovermode 0 –arraycommpath 0
#
navicli -h <SP_A_IP_address> storagegroup
-setpath -o -gname <storage_group_name>
-hbauid <blade_port_1_WWN>
-sp a -spport 1 –type 32 –failovermode 0 –arraycommpath 0
#
navicli -h <SP_A_IP_address> storagegroup
-setpath -o -gname <storage_group_name>
-hbauid <blade_port_1_WWN>
-sp b -spport 1 –type 32 –failovermode 0 –arraycommpath 0
2. For dual switches, enter the following:
#
navicli -h <SP_A_IP_address> storagegroup
-setpath -o -gname <storage_group_name>
-hbauid <blade_port_0_WWN>
-sp a -spport 0 –type 32 –failovermode 0 –arraycommpath 0
#
navicli -h <SP_A_IP_address> storagegroup
-setpath -o -gname <storage_group_name>
-hbauid <blade_port_0_WWN>
-sp b -spport 1 –type 32 –failovermode 0 –arraycommpath 0
#
navicli -h <SP_A_IP_address> storagegroup
-setpath -o -gname <storage_group_name>
-hbauid <blade_port_1_WWN>
-sp a -spport 1 –type 32 –failovermode 0 –arraycommpath 0
#
navicli -h <SP_A_IP_address> storagegroup
-setpath -o -gname <storage_group_name>
-hbauid <blade_port_1_WWN>
-sp b -spport 0 –type 32 –failovermode 0 –arraycommpath 0
# navicli -h 128.221.252.200 storagegroup
-setpath -o -gname Celerra_RTP55Cs0
-hbauid 50:06:01:60:00:60:03:7f:50:06:01:60:00:60:03:7f
-sp a -spport 0 –type 32 –failovermode 0 –arraycommpath 0
