If you are using one switch to connect a CX4-960 array, connect the cables as shown in
the example in
2
2
Figure 170 CX4-960 connected to a single switch (example)
The array SAN ports 2 and 3 are used in this example, but you can use any two ports
on each SP:
1. Connect SP A slot 0, port 2 to the switch.
2. Connect SP B slot 0, port 2 to the switch.
3. Connect SP A slot 0, port 3 to the switch.
4. Connect SP B slot 0, port 3 to the switch.
5. Record the SP ports you connected to the switch ports by using the
cabling worksheet" on page
Cable Connections from Fibre Channel Switch to Storage
Figure 170.
3
SP B
4
2
SP A
3
1
3
273.
EMC CONFIDENTIAL
Switch
CNS-000895
Connecting a CLARiiON CX4-960 array
"FC/FCoE
