Control Station 0 networking worksheet

You will need the following information for the Control Station 0 networking
configuration. This information is entered during
.
on page 139
If you need to change the private network addresses because of a conflict with the
customer's public network, fill out the
continuing.
Primary Internal (Private) Network Setup
Hostname: emcnas_i0
IP Address_____ . _____ . _____ . 100 (default 128.221.252.100)
Netmask: 255.255.255.0
IPMI Network Setup
Hostname: emcnas_ipmi
IP Address _____ . _____ . _____ . 100 (default 128.221.254.100)
Netmask: 255.255.255.0
Backup Internal (Private) Network Setup
Hostname: emcnas_i1
IP Address _____ . _____ . _____ . 100 (default 128.221.253.100)
Netmask: 255.255.255.0
Specify How to Set the Control Station's Public Network Address
❑
Static IP Address
❑
BOOTP (Bootstrap Protocol; network must have BOOTP server)
❑
DHCP (dynamic host configuration protocol; network must have DHCP
server)
Configure TCP/IP (if Static IP Address selected)
IP Address _____ . _____ . _____ . _____
This is the IP address of port eth3 that is cabled to the customer's public or
maintenance LAN.
Netmask _____ . _____ . _____ . _____
Default Gateway (IP) Address _____ . _____ . _____ . _____
Primary Nameserver _____ . _____ . _____ . _____
Configure Network
Domain Name ___________________________________________
This is the domain name of the customer's network to which the Control
Station is attached.
Hostname _______________________________________________
Secondary Nameserver (optional) _____ . _____ . _____ . _____
Tertiary Nameserver (optional)
EMC CONFIDENTIAL
"Step 2: Install latest File OE on CS 0"
"Private LAN worksheet" on page 280
_____ . _____ . _____ . _____

Control Station 0 networking worksheet

Setup Worksheets
before
