Complete Phase 3 Installation
Figure 96
Figure 97
152 EMC VNX VG2/VG8 Gateway Configuration Setup Guide
Number of Fibre Channel switches screen
The system prompts you to type switch 1 information, as shown in
c. Type the Fibre Channel switch information, as shown in
to select Ok, and then press Enter. You can get the FC switch information from
the "FC/FCoE cabling worksheet,"
Fibre Channel switch 1 settings
d. If you selected more than one FC switch for the new array, the system prompts
you to enter information for the next switch (similar to
Fibre Channel switch information for the next switch, tab to Ok, and then
press Enter. Repeat this process for each FC switch.
Note: Skip this step if you only have one FC switch.
The system prompts as to whether you would like to auto-detect the array
fibre ports on the switch, as shown in
e. Select Yes and press Enter to have the gateway system automatically detect
which ports the array backend is using on the FC switch.
Figure
on page 273.
Figure
Figure 98 on page 153.
Figure 96.
97, press Tab
97). Type the
