EMC VNX VG2 Setup Manual page 255

If you are using one switch to connect a CLARiiON CX700 array, connect the cables
(Figure 162). This example uses CLARiiON array SAN ports 0 and 1, but you can use
any two ports on each SP:
SP B
3 2 1 0
SP A
0 1 2 3
Figure 162 CLARiiON CX700 connected to a single switch
1. Connect SP A port 0 to the switch.
2. Connect SP B port 0 to the switch.
3. Connect SP A port 1 to the switch.
4. Connect SP B port 1 to the switch.
5. Record which SP ports you connected to which switch ports using the
cabling worksheet" on page
Note: If you did not use the default SP and FC switch cabling, you must manually select the FC
switch ports the array will use in
Cable Connections from Fibre Channel Switch to Storage
Switch
2
4
3
1
CIP-000130
273.
"Step 2: Install latest File OE on CS 0" on page
Connecting a CLARiiON CX700 array
EMC CONFIDENTIAL
"FC/FCoE
139.
