Two 1-GbE copper and two 1-GbE optical ports
Figure 16
SFP modules The gigabit Fibre Channel ports and the optical Gigabit Ethernet ports on some I/O
modules use optical SFP modules
in the I/O module ports.
Dust cover
Figure 17 Optical SFP module
Three types of SFP modules are available.
modules.
SFP module types
Table 3
SFP module type
SFP transceiver multimode for 1-, 2-, or 4-GbE ports
SFP+ transceiver limiting multimode for 10-GbE ports
SFP+ transceiver multimode for 2-, 4-, or 8-GbE ports
CNS-001856
(Figure
SFP
Spring
release
EMC CONFIDENTIAL
17). The SFP modules are factory-installed
CNS-001857
Table 3 lists the part numbers for these
SFP module part number
019-078-032
019-078-041
019-078-042
