Register Initiator Record dialog box (example)
Figure 157
5. Enter these values for the first blade port and click OK:
Field
Initiator Type
Failover mode
New Host
Host Name
IP Address
Vendor
Model
ArrayCommPath
Unit Serial Number
6. For each additional blade port, enter these values and click OK:
Field
Initiator Type
Failover mode
Existing Host
Vendor
Model
ArrayCommPath
Unit Serial Number
Manually Zone Switches and Configure System LUNs
Value
Celerra (or CLARiiON Open if pre-R30 code)
Legacy failovermode 0
Select this radio button
CS 0 host name (for example, Celerra_RTP55Cs0)
CS 0 IP address
Optional
Optional
Uncheck this check box
Array
Value
Celerra (use CLARiiON Open for pre-R30 code)
Legacy failovermode 0
Select this radio button, then browse to the host name
that you created in step 5 and select it.
Optional
Optional
Uncheck this check box
Array
Create control LUNs on VNX array
