Connect Cables for a Direct-connected VG8
Connecting a
VNX5700 or
VNX7500 array
116 EMC VNX VG2/VG8 Gateway Configuration Setup Guide
Use Figure 80 on page 117
VNX SPs. You must use SFPs to connect the ports
provides more information):
Note: Figure 80 on page 117
illustration purposes. The following steps describe how to connect the cables for a
maximum VNX VG8 configuration (8 blades). The maximum number of connections
depends on the availability of ports in the VNX SPs.
1. Connect blade 2, slot 0, port 0 to SP A slot 4, port 0 (cable 1 in
page 117).
2. Connect blade 2, slot 0, port 1 to SP B slot 4, port 0 (cable 2 in
page 117).
3. Connect blade 3, slot 0, port 0 to SP A slot 4, port 1 (cable 3 in
page 117).
4. Connect blade 3, slot 0, port 1 to SP B slot 4, port 1 (cable 4 in
page 117).
5. Connect blade 4 slot 0, port 0 to SP A slot 4, port 2.
6. Connect blade 4 slot 0, port 1 to SP B slot 4, port 2.
7. Connect blade 5 slot 0, port 0 to SP A slot 4, port 3.
8. Connect blade 5 slot 0, port 1 to SP B slot 4, port 3.
9. Connect blade 6 slot 0, port 0 to SP A slot 3, port 0.
10. Connect blade 6 slot 0, port 1 to SP B slot 3, port 0.
11. Connect blade 7 slot 0, port 0 to SP A slot 3, port 1.
12. Connect blade 7 slot 0, port 1 to SP B slot 3, port 1.
13. Connect blade 8 slot 0, port 0 to SP A slot 3, port 2.
14. Connect blade 8 slot 0, port 1 to SP B slot 3, port 2.
15. Connect blade 9 slot 0, port 0 to SP A slot 3, port 3.
16. Connect blade 9 slot 0, port 1 to SP B slot 3, port 3.
to connect the Fibre Channel cables from the blades to the
("SFP modules" on page 43
shows only the first four cable connections for
Figure 80 on
Figure 80 on
Figure 80 on
Figure 80 on
