EMC VNX VG2 Setup Manual page 67

If you are using one switch to connect a VNX5500 array, connect the cables as shown
in the example in
SP B
2
Figure 32 VNX5500 connected to a single switch (example)
The array SAN ports 2 and 3 are used in this example, but you can use any two ports
on each SP:
1. Connect SP A slot 0, port 2 to the switch.
2. Connect SP B slot 0, port 2 to the switch.
3. Connect SP A slot 0, port 3 to the switch.
4. Connect SP B slot 0, port 3 to the switch.
5. Record the SP ports you connected to the switch ports by using the
cabling worksheet" on page
Figure 32.
SP A
3 3 3
2 2
1 1
0 0
4
273.
EMC CONFIDENTIAL
Connect Cables for a Fabric-connected VG2
Switch
1
CNS-000892
Step 2: Array Fibre Channel cables
"FC/FCoE
67
