Figure 36
Connecting
additional arrays
If you are using one switch to connect a VNX5100 array, connect the cables as shown
in the example in Figure 34.
SP B
3
2
1
0
2
VNX5100 connected to a single switch (example)
The array SAN ports 2 and 3 are used in this example, but you can use any two ports
on each SP:
1. Connect SP A slot 0, port 2 to the switch.
2. Connect SP B slot 0, port 2 to the switch.
3. Connect SP A slot 0, port 3 to the switch.
4. Connect SP B slot 0, port 3 to the switch.
5. Record the SP ports you connected to the switch ports by using the
cabling worksheet" on page
Appendix G, "Cable Connections from Fibre Channel Switch to Storage Array,"
provides information on cabling legacy CLARiiON arrays.
If you are connecting multiple arrays to the VNX gateway system, connect the
additional arrays to the Fibre Channel switch after the installation of the EMC NAS
software. Connect the Fibre Channel cables for the additional arrays as shown in the
preceding sections. Chapter 10, "Complete Phase 3 Installation,"
instructions.
Connect Cables for a Fabric-connected VG2
Switch
SP A
3 3
2
1
1
0
4
CNS-000892
273.
Step 2: Array Fibre Channel cables
EMC CONFIDENTIAL
"FC/FCoE
provides detailed
71
