Connect Cables for a Direct-connected VG2
Connecting a
VNX5700 or
VNX7500 array
VNX VG2
SPE
Figure 47
82 EMC VNX VG2/VG8 Gateway Configuration Setup Guide
Use Figure 47 to connect the Fibre Channel cables from the blades to the array SPs.
You must use SFPs to connect the ports (see
1. Connect blade 2, slot 0, port 0 to SP A slot 4, port 0 (cable 1 in
2. Connect blade 2, slot 0, port 1 to SP B slot 4, port 0 (cable 2 in
3. For the two-blade VG2, connect blade 3, slot 0, port 0 to SP A slot 4, port 1 (cable 3
in Figure 47).
4. For the two-blade VG2, connect blade 3, slot 0, port 1 to SP B slot 4, port 1 (cable 4
in Figure 47).
B
Port 0
Port 1
4
SP B
VNX5700/VNX7500
0 1 2
Fibre Channel cables connect VG2 blades to VNX5700/VNX7500 array (example)
"SFP modules" on page
Blade 2
2 1
Port 0
SP A
3 4 0 1
43):
Figure 47).
Figure 47).
A
3
Port 1
2 3 4
