Setup Worksheets

Private LAN worksheet

Primary private LAN

Table 14
280 EMC VNX VG2/VG8 Gateway Configuration Setup Guide
The blades and Control Station communicate with each other by using a private
LAN. By default, this network uses IP addresses on the 128.221.252 and 128.221.253
subnets.
Note: During fresh installs of NAS software, the private LAN addresses can be changed, if
required; otherwise, the installation program uses default addresses.
If the customer's existing public IP network also uses addresses on these subnets, you
need to change the private network addresses of the VNX gateway to different
subnets. The VNX gateway cannot have the same subnets configured for both its
private (internal) and public (external) network connections. Multiple VNX gateways
can all use the same private LAN addresses without conflict.
private (internal) LAN" on page 25
During Control Station installation, the setup script will prompt you for these
addresses. You can either accept the default values or enter the new addresses at that
time. The script changes the blade addresses to match what you enter for the Control
Station.
Table 14 lists the default primary private LAN addresses.
Fill in the new address value you want to use. The first three octets of the address are
the same for all components in the network. Note that the final octet of the addresses
must be the value shown in the table.
Primary private network addresses
Name in
Component /etc/hosts Default address
Control Station emcnas_i0
128.221.252
Blade 2 server_2
Blade 3 server_3
Blade 4 server_4
Blade 5 server_5
Blade 6 server_6
Blade 7 server_7
Blade 8 server_8
Blade 9 server_9
The netmask is always 255.255.255.0.
provides more information.
New IP address
.100
________.________._______
.2
.3
.4
.5
.6
.7
.8
.9
"Configuring the
.100
.2
.3
.4
.5
.6
.7
.8
.9
