EMC VNX VG2 Setup Manual page 35

Control Station The VG2/VG8 system provides one or two Control Station assemblies. Each
components
assembly includes:
Control Station
◆
Blank front panel (bezel)
◆
Serial modem cable 10 ft (attached) for the CallHome modem; the label clip
◆
(Figure
Label for serial modem cable for the CallHome modem
Figure 2
One 25 ft CAT5 LAN cable (attached) for each Control Station to connect to the
◆
customer's Ethernet network.
Two 5.5 ft CAT5E LAN cables for each Control Station to connect to the two
◆
management module ports.
One crossover IPMI cable in the Control Station 1 kit (if ordered) to connect the
◆
Control Stations; the label clips
Figure 3 Labels for IPMI cable between Control Stations
Miscellaneous Miscellaneous components may include:
components
One CallHome modem with power supply cable
◆
Accessory kit, including:
◆
• One crossover LAN cable for connecting your service laptop
• One null-modem serial cable for connecting the service laptop
• One null modem micro-DB-9 to DB9/F serial cable for connecting to the
Accessories including labels and keys
◆
Software kit
◆
Two 16-, 20-, or 32-port Fibre Channel (FC) switches or two 24- or 48-port Fibre
◆
Channel over Ethernet (FCoE) switches (Brocade 8000B or Cisco 5010/5020) with
appropriate cables (optical cables for FC switches; optical or active twinaxial
cables for FCoE switches).
Rail kit including mounting rails and hardware for each component (if system is
◆
not already racked)
2) helps identify this cable.
CS
CNS-001325
CS 1 CS Port
management module
EMC CONFIDENTIAL
(Figure 3) help to identify the cable.
CS 0 CS Port
CNS-001639
Step 1: Check components
Before Installing
35
