NAS Install Options
Figure 122
Figure 123
210 EMC VNX VG2/VG8 Gateway Configuration Setup Guide
14. To confirm the Gateway selection, tab to Ok and press Enter.
The system prompts you for the backend type
Backend settings
15. Select CLARiiON or Symmetrix and press Enter.
A confirmation prompt appears.
16. Tab to Ok and press Enter to confirm the type of backend for the gateway.
17. If prompted (Figure 123):
a. Enter the values for the IP addresses of SP A and SP B in the designated fields.
Obtain these values from the
b. If security is initialized on the backend, enter the administrator login and
password for the VNX array. Otherwise, leave these fields blank.
c. Tab to Ok and press Enter. The system will now verify the IP addresses.
Note: This prompt is not displayed for gateway systems that are using a Symmetrix
backend for the boot array.
VNX SP settings
(Figure 122).
"VNX boot array worksheet" on page 276.
