Setup Worksheets - EMC VNX VG2 Setup Manual

This appendix contains worksheets you can use to collect and record configuration
information. Ask the customer for this information as needed. When setup is
complete, give these worksheets to the customer:
Site preparation worksheet ........................................................................................ 272
◆
FC/FCoE cabling worksheet ..................................................................................... 273
◆
VNX boot array worksheet ........................................................................................ 276
◆
Control Station 0 networking worksheet................................................................. 277
◆
Control Station 1 networking worksheet................................................................. 278
◆
Private LAN worksheet.............................................................................................. 280
◆
Phase 2 completion hand-off worksheet.................................................................. 282
◆
Setup Celerra wizard worksheets ............................................................................. 283
◆
iSCSI wizard worksheets............................................................................................ 296
◆
ConnectHome configuration worksheet.................................................................. 298
◆
Note: Some worksheets in this appendix contain rows to collect information about the blades
(data movers) in your system. If your system has fewer blades than the number of worksheet
rows, complete only the needed rows.
