Fc Closed Loop - Danfoss VLT AQUA Drive FC 202 Programming Manual

Parameter Lists

4.1.17 20-** FC Closed Loop

Par. No. # Parameter description
20-0* Feedback
20-00 Feedback 1 Source
20-01 Feedback 1 Conversion
20-02 Feedback 1 Source Unit
20-03 Feedback 2 Source
20-04 Feedback 2 Conversion
20-05 Feedback 2 Source Unit
20-06 Feedback 3 Source
20-07 Feedback 3 Conversion
20-08 Feedback 3 Source Unit
20-12 Reference/Feedback Unit
20-2* Feedback/Setpoint
20-20 Feedback Function
20-21 Setpoint 1
20-22 Setpoint 2
20-23 Setpoint 3
20-7* PID Autotuning
20-70 Closed Loop Type
20-71 PID Performance
20-72 PID Output Change
20-73 Minimum Feedback Level
20-74 Maximum Feedback Level
20-79 PID Autotuning
20-8* PID Basic Settings
20-81 PID Normal/ Inverse Control
20-82 PID Start Speed [RPM]
20-83 PID Start Speed [Hz]
20-84 On Reference Bandwidth
20-9* PID Controller
20-91 PID Anti Windup
20-93 PID Proportional Gain
20-94 PID Integral Time
20-95 PID Differentiation Time
20-96 PID Diff. Gain Limit
MG20O702
Programming Guide
Default value
[2] Analog input 54
[0] Linear
null
[0] No function
[0] Linear
null
[0] No function
[0] Linear
null
null
[4] Maximum
0.000 ProcessCtrlUnit
0.000 ProcessCtrlUnit
0.000 ProcessCtrlUnit
[0] Auto
[0] Normal
0.10 N/A
-999999.000 ProcessCtrlUnit
999999.000 ProcessCtrlUnit
[0] Disabled
[0] Normal
ExpressionLimit
ExpressionLimit
5 %
[1] On
2.00 N/A
8.00 s
0.00 s
5.0 N/A
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
4-set-up Change Conver-
during sion index
operation
All set-ups TRUE -
All set-ups FALSE -
All set-ups TRUE -
All set-ups TRUE -
All set-ups FALSE -
All set-ups TRUE -
All set-ups TRUE -
All set-ups FALSE -
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -3
2 set-ups TRUE -
2 set-ups TRUE -
2 set-ups TRUE -2
2 set-ups TRUE -3
2 set-ups TRUE -3
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE 67
All set-ups TRUE -1
All set-ups TRUE 0
All set-ups TRUE -
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -1
Type
Uint8
Uint8
4 4
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Int32
Int32
Int32
Uint8
Uint8
Uint16
Int32
Int32
Uint8
Uint8
Uint16
Uint16
Uint8
Uint8
Uint16
Uint32
Uint16
Uint16
221
