Danfoss VLT AQUA Drive FC 202 Programming Manual page 189

Parameter Description
26-44 Terminal X42/7 Timeout Preset
Range: Function:
0 % [0 - 100 Holds the preset level of terminal X42/7.
*
%] In case of a bus timeout and a timeout function
is selected in parameter 26-50 Terminal X42/9
Output the output will preset to this level.
26-50 Terminal X42/9 Output
Option: Function:
Set the function of terminal X42/9.
[0] No operation
[100] Output freq. 0-100 Hz, (0-20 mA)
0-100
[101] Reference Min- Minimum reference - Maximum
Max reference, (0-20 mA)
[102] Feedback -200% to +200% of
+-200% parameter 3-03 Maximum Reference, (0-20
mA)
[103] Motor cur. 0- 0 - Inverter Max. Current
Imax (parameter 16-37 Inv. Max. Current), (0-20
mA)
[104] Torque 0-Tlim 0 - Torque limit (parameter 4-16 Torque
Limit Motor Mode), (0-20 mA)
[105] Torque 0-Tnom 0 - Motor rated torque, (0-20 mA)
[106] Power 0-Pnom 0 - Motor rated power, (0-20 mA)
[107] Speed 0- 0 - Speed High Limit
HighLim (parameter 4-13 Motor Speed High Limit
[RPM] and parameter 4-14 Motor Speed
High Limit [Hz]), (0-20 mA)
[108] Torque +-160%
[109] Out frq 0-Fmax
[113] Ext. Closed 0 - 100%, (0-20 mA)
Loop 1
[114] Ext. Closed 0 - 100%, (0-20 mA)
Loop 2
[115] Ext. Closed 0 - 100%, (0-20 mA)
Loop 3
[139] Bus ctrl. 0 - 100%, (0-20 mA)
[141] Bus ctrl t.o. 0 - 100%, (0-20 mA)
26-51 Terminal X42/9 Min. Scale
Range: Function:
0 % [0 - Scale the minimum output of the selected analog
*
200 %] signal at terminal X42/9, as a percentage of the
maximum signal level. E.g. if a 0 V is desired at
25% of the maximum output value. Then
programme 25%. Scaling values up to 100% can
never be higher than the corresponding setting in
parameter 26-52 Terminal X42/9 Max. Scale.
See principle graph for parameter 6-51 Terminal 42 Output
Min Scale.
MG20O702
Programming Guide
26-52 Terminal X42/9 Max. Scale
Range:
100
% 200
*
%]
See principle graph for parameter 6-52 Terminal 42 Output
Max Scale.
26-53 Terminal X42/9 Bus Control
Range:
0 %
*
26-54 Terminal X42/9 Timeout Preset
Range:
0 %
*
%]
26-60 Terminal X42/11 Output
Option:
[0] No operation
[100] Output freq.
0-100
[101] Reference Min-
Max
[102] Feedback
+-200%
[103] Motor cur. 0-
Imax
[104] Torque 0-Tlim
[105] Torque 0-Tnom
[106] Power 0-Pnom
[107] Speed 0-
HighLim
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Function:
[0 - Scale the maximum output of the selected analog
signal at terminal X42/9. Set the value to the
maximum value of the voltage signal output.
Scale the output to give a voltage lower than 10
V at full scale; or 10 V at an output below 100%
of the maximum signal value. If 10 V is the
desired output current at a value between
0-100% of the full-scale output, programme the
percentage value in the parameter, i.e. 50% = 10
V. If a voltage between 0 and 10V is desired at
maximum output, calculate the percentage as
follows:
i.e.
V
10
5 V : x 100% = 200%
V
5
Function:
[0 - 100 %] Holds the level of terminal X42/9 if
controlled by bus.
Function:
[0 - 100 Holds the preset level of terminal X42/9.
In case of a bus timeout and a timeout function
is selected in parameter 26-60 Terminal X42/11
Output the output will preset to this level.
Function:
Set the function of terminal X42/11.
0-100 Hz, (0-20 mA)
Minimum reference - Maximum
reference, (0-20 mA)
-200% to +200% of
parameter 3-03 Maximum Reference, (0-20
mA)
0 - Inverter Max. Current
(parameter 16-37 Inv. Max. Current), (0-20
mA)
0 - Torque limit (parameter 4-16 Torque
Limit Motor Mode), (0-20 mA)
0 - Motor rated torque, (0-20 mA)
0 - Motor rated power, (0-20 mA)
0 - Speed High Limit
(parameter 4-13 Motor Speed High Limit
3 3
