Parameter Description
3.14 Parameters 15-** Frequency Converter
Information
Parameter group containing frequency converter
information such as operating data, hardware configu-
ration and software versions.
3.14.1 15-0* Operating Data
15-00 Operating hours
Range: Function:
0 h [0 - 2147483647 h] View how many hours the frequency
*
converter has run. The value is saved
when the frequency converter is
turned off.
15-01 Running Hours
Range: Function:
0 h [0 - View how many hours the motor has run.
*
2147483647 h] Reset the counter in
parameter 15-07 Reset Running Hours
Counter. The value is saved when the
frequency converter is turned off.
15-02 kWh Counter
Range: Function:
0 kWh [0 - Registering the power consumption of
*
2147483647 the motor as a mean value over one
kWh] hour. Reset the counter in
parameter 15-06 Reset kWh Counter.
15-03 Power Up's
Range: Function:
0 [0 - 2147483647 ] View the number of times the frequency
*
converter has been powered up.
15-04 Over Temp's
Range: Function:
0 [0 - 65535 ] View the number of frequency converter
*
temperature faults which have occurred.
15-05 Over Volt's
Range: Function:
0 [0 - 65535 ] View the number of frequency converter
*
overvoltages which have occurred.
15-06 Reset kWh Counter
Option: Function:
[0] Do not reset No reset of the kWh counter is desired.
[1] Reset counter Press [OK] to reset the kWh counter to zero
(see parameter 15-02 kWh Counter).
MG20O702
Programming Guide
NOTICE
The reset is carried out by pressing [OK].
15-07 Reset Running Hours Counter
Option:
[0] Do not reset No reset of the Running Hours counter is
[1] Reset
counter
15-08 Number of Starts
Range:
0 [0 - 2147483647 ] This is a read out parameter only. The
*
NOTICE
This parameter is reset when resetting
parameter 15-07 Reset Running Hours Counter.
3.14.2 15-1* Data Log Settings
The Data Log enables continuous logging of up to 4 data
sources (15-10 Logging Source) at individual rates
(parameter 15-11 Logging Interval). A trigger event
(parameter 15-12 Trigger Event) and window
(parameter 15-14 Samples Before Trigger) are used to start
and stop the logging conditionally.
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Function:
desired.
Select [1] Reset counter and press [OK] to reset
the Running Hours counter
(parameter 15-01 Running Hours) and
parameter 15-08 Number of Starts to zero (see
also parameter 15-01 Running Hours).
Function:
counter shows the numbers of starts
and stops caused by a normal Start/Stop
command and/or when entering/leaving
sleep mode.
