Danfoss VLT AQUA Drive FC 202 Programming Manual page 187

Parameter Description
26-15 Term. X42/1 High Ref./Feedb. Value
Range: Function:
100 [-999999.999 - Enter the analog input scaling value
*
999999.999 ] that corresponds to the high voltage
value set in parameter 26-11 Terminal
X42/1 High Voltage.
26-16 Term. X42/1 Filter Time Constant
Range: Function:
0.001 s [0.001 - Enter the time constant. This is a first-
*
10 s] order digital low pass filter time constant
for suppressing noise in terminal X42/1. A
high time constant value improves
dampening but also increases the time
delay through the filter.
NOTICE
This parameter cannot be adjusted
while the motor is running.
26-17 Term. X42/1 Live Zero
Option: Function:
This parameter makes it possible to enable the Live
Zero monitoring. E.g. where the analog input is a
of the frequency converter control, rather than
being used as of a decentral I/O system, such as a
Building Management System.
[0] Disabled
[1] Enabled
26-20 Terminal X42/3 Low Voltage
Range: Function:
0.07 V [ 0 - par. Enter the low voltage value. This analog
*
6-31 V] input scaling value should correspond to
the low reference/feedback value set in
parameter 26-24 Term. X42/3 Low Ref./Feedb.
Value.
26-21 Terminal X42/3 High Voltage
Range: Function:
10 V [ par. 6-30 Enter the high voltage value. This analog
*
- 10 V] input scaling value should correspond to the
high reference/feedback value set in
parameter 26-25 Term. X42/3 High Ref./Feedb.
Value.
26-24 Term. X42/3 Low Ref./Feedb. Value
Range: Function:
0 [-999999.999 - Enter the analog input scaling value
*
999999.999 ] that corresponds to the low voltage
value set in parameter 26-20 Terminal
X42/3 Low Voltage.
MG20O702
Programming Guide
26-25 Term. X42/3 High Ref./Feedb. Value
Range:
100
*
999999.999 ]
26-26 Term. X42/3 Filter Time Constant
Range:
0.001 s
*
26-27 Term. X42/3 Live Zero
Option:
[0] Disabled
[1] Enabled
26-30 Terminal X42/5 Low Voltage
Range:
0.07 V
*
26-31 Terminal X42/5 High Voltage
Range:
10 V
*
- 10 V]
26-34 Term. X42/5 Low Ref./Feedb. Value
Range:
0 [-999999.999 -
*
999999.999 ]
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Function:
[-999999.999 - Enter the analog input scaling value
that corresponds to the high voltage
value set in parameter 26-21 Terminal
X42/3 High Voltage.
Function:
[0.001 - Enter the time constant. This is a first-
10 s] order digital low pass filter time constant
for suppressing noise in terminal X42/3. A
high time constant value improves
dampening but also increases the time
delay through the filter.
NOTICE
This parameter cannot be adjusted
while the motor is running.
Function:
This parameter makes it possible to enable the Live
Zero monitoring. E.g. where the analog input is a
of the frequency converter control, rather than
being used as of a decentral I/O system, such as a
Building Management System.
Function:
[ 0 - par. Enter the low voltage value. This analog
6-31 V] input scaling value should correspond to
the low reference/feedback value set in
parameter 26-34 Term. X42/5 Low Ref./Feedb.
Value.
Function:
[ par. 6-30 Enter the high voltage value. This analog
input scaling value should correspond to the
high reference/feedback value set in
parameter 26-35 Term. X42/5 High Ref./Feedb.
Value.
Function:
Enter the analog input scaling value
that corresponds to the low voltage
value set in parameter 26-30 Terminal
X42/5 Low Voltage.
