How to Programme
The parameter selection is effected with the navigation
keys. The parameters in Table 2.1 are accessible.
2 2
Parameter
Parameter 0-01 Language
1-20 Motor Power [kW]
Parameter 1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
5-12 Terminal 27 Digital Input
1-29 Automatic Motor Adaptation (AMA)
3-02 Minimum Reference
3-03 Maximum Reference
3-41 Ramp 1 Ramp Up Time
3-42 Ramp 1 Ramp Down Time
Parameter 3-13 Reference Site
Table 2.1 Selection of Parameter
* If terminal 27 is set to [0] No function, no connection to +24 V on
terminal 27 is necessary.
Select Changes made to get information about:
•
the last 10 changes. Use the [
keys to scroll between the last 10 changed
parameters.
•
the changes made since default setting.
Select Loggings to get information about the display line
read-outs. The information is shown as graphs.
Only display parameters selected in parameter 0-20 Display
Line 1.1 Small and 0-24 Display Line 3 Large can be viewed.
It is possible to store up to 120 samples in the memory for
later reference.
18
Programming Guide
Setting
[kW]
[V]
[Hz]
[A]
[RPM]
[0] No function*
[1] Enable complete
AMA
[RPM]
[RPM]
[s]
[s]
▲ ▼
] [ ] navigation
