Parameter Description
15-23 Historic log: Date and Time
Array [50]
Range:
Size related
*
3 3
3.14.4 15-3* Alarm Log
Parameters in this group are array parameters, where up to
10 fault logs can be viewed. [0] is the most recent logged
data, and [9] the oldest. Error codes, values, and time
stamp can be viewed for all logged data.
15-30 Alarm Log: Error Code
Array [10]
Range:
0 [0 - 255 ] View the error code and look up its meaning in
*
15-31 Alarm Log: Value
Array [10]
Range:
0 [-32767 - 32767 ] View an extra description of the error.
*
15-32 Alarm Log: Time
Array [10]
Range:
0 s [0 - 2147483647 s] View the time when the logged event
*
15-33 Alarm Log: Date and Time
Array [10]
Range:
Size related
*
15-34 Alarm Log: Setpoint
Array [10]
Range:
0 ProcessCtrlUnit
122
Function:
[ 0 - 0 ] Array parameter; Date & Time 0 - 49: This
parameter shows at which time the
logged event occurred.
Function:
chapter 5 Troubleshooting.
Function:
This parameter is mostly used in
combination with alarm 38 'internal
fault'.
Function:
occurred. Time is measured in seconds
from frequency converter start-up.
Function:
[ 0 - 0 ] Array parameter; Date & Time 0 - 9: This
parameter shows at which time the
logged event occurred.
Function:
[-999999.999 - Array parameter, status
*
999999.999 value 0 - 9. This
ProcessCtrlUnit] parameter shows the
status of the alarm:
0: Alarm inactive
1: Alarm active
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Programming Guide
15-35 Alarm Log: Feedback
Array [10]
Range:
0 ProcessCtrlUnit
15-36 Alarm Log: Current Demand
Array [10]
Range:
0 %
*
15-37 Alarm Log: Process Ctrl Unit
Array [10]
Option:
[0]
[1]
[5]
[10]
[11]
[12]
[20]
[21]
[22]
[23]
[24]
[25]
[30]
[31]
[32]
[33]
[34]
[40]
[41]
[45]
[60]
[70]
[71]
[72]
[73]
[74]
[75]
[80]
[120]
[121]
[122]
[123]
[124]
[125]
[126]
[127]
[130]
[131]
[132]
[140]
[-999999.999 - 999999.999
*
ProcessCtrlUnit]
Function:
[0 - 100 %]
Function:
-
%
PPM
1/min
RPM
Pulse/s
l/s
l/min
l/h
m³/s
m³/min
m³/h
kg/s
kg/min
kg/h
t/min
t/h
m/s
m/min
m
°C
mbar
bar
Pa
kPa
m WG
mm Hg
kW
GPM
gal/s
gal/min
gal/h
CFM
ft³/s
ft³/min
ft³/h
lb/s
lb/min
lb/h
ft/s
Function:
MG20O702
