Parameter Description
[47] Bus Ctrl 0 if
timeout
[55] Pulse output
[60] Comparator 0
3 3
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[70] Logic Rule 0
[71] Logic Rule 1
[72] Logic Rule 2
[73] Logic Rule 3
[74] Logic Rule 4
[75] Logic Rule 5
[80] SL Digital
Output A
[81] SL Digital
Output B
[82] SL Digital
Output C
72
Programming Guide
See parameter group 13-1* Comparators. If
Comparator 0 is evaluated as TRUE, the
output goes high. Otherwise, it is be low.
See parameter group 13-1* Comparators. If
Comparator 1 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter group 13-1* Comparators. If
Comparator 2 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter group 13-1* Comparators. If
Comparator 3 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter group 13-1* Comparators. If
Comparator 4 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter group 13-1* Comparators. If
Comparator 5 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter group 13-4* Logic Rules. If
Logic Rule 0 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter group 13-4* Logic Rules. If
Logic Rule 1 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter group 13-4* Logic Rules. If
Logic Rule 2 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter group 13-4* Logic Rules. If
Logic Rule 3 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter group 13-4* Logic Rules. If
Logic Rule 4 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter group 13-4* Logic Rules. If
Logic Rule 5 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter 13-52 SL Controller Action.
The output goes high whenever the Smart
Logic Action [38] Set digital out A high is
executed. The output goes low whenever
the Smart Logic Action [32] Set digital out
A low is executed.
See parameter 13-52 SL Controller Action.
The output goes high whenever the Smart
Logic Action [39] Set digital out B high is
executed. The output goes low whenever
the Smart Logic Action [33] Set digital out
B low is executed.
See parameter 13-52 SL Controller Action.
The output goes high whenever the Smart
Logic Action [40] Set digital out C high is
executed. The output goes low whenever
the Smart Logic Action [34] Set digital out
C low is executed.
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
[83] SL Digital See parameter 13-52 SL Controller Action.
Output D The output goes high whenever the Smart
Logic Action [41] Set digital out D high is
executed. The output goes low whenever
the Smart Logic Action [35] Set digital out
D low is executed.
[84] SL Digital See parameter 13-52 SL Controller Action.
Output E The output goes high whenever the Smart
Logic Action [42] Set digital out E high is
executed. The output goes low whenever
the Smart Logic Action [36] Set digital out
E low is executed.
[85] SL Digital See parameter 13-52 SL Controller Action.
Output F The output goes high whenever the Smart
Logic Action [43] Set digital out F high is
executed. The output goes low whenever
the Smart Logic Action [37] Set digital out
F low is executed.
[160] No alarm Output is high when no alarm is present.
[161] Running The output is high when the frequency
reverse converter is running counter clockwise
(the logical product of the status bits
'running' AND 'reverse').
[165] Local Output is high when
reference parameter 3-13 Reference Site = [2] Local or
active when parameter 3-13 Reference Site = [0]
Linked to hand auto at the same time as
the LCP is in Hand on mode.
[166] Remote Output is high when
reference parameter 3-13 Reference Site is set to [1]
active Remote or [0] Linked to hand/auto while
the LCP is in Auto On mode.
[167] Start Output is high when there is an active
command Start command. (I.e.[Auto On] and a start
active command via digital input or bus is active,
or [Hand On].
NOTICE
All inverse Stop/Coast commands
must be inactive.
[168] Drive in hand Output is high when the frequency
mode converter is in Hand mode (as indicated
by the LED light above [Hand on].
[169] Drive in auto Output is high when the frequency
mode converter is in Auto mode (as indicated by
the LED light above [Auto on].
[180] Clock Fault The clock function has been reset to
default (2000-01-01) because of a power
failure.
[181] Preventive One or more of the Preventive
Maintenance Maintenance Events programmed in
parameter 23-10 Maintenance Item has
passed the time for the specified action in
parameter 23-11 Maintenance Action.
[182] Deragging Deragging is active.
[188] AHF Capacitor See parameter 5-80 AHF Cap Reconnect
Connect Delay.
