4.1.25 29-** Water Application Functions

Par. Parameter description
No. #
29-0* Pipe Fill
29-00 Pipe Fill Enable
29-01 Pipe Fill Speed [RPM]
29-02 Pipe Fill Speed [Hz]
29-03 Pipe Fill Time
29-04 Pipe Fill Rate
29-05 Filled Setpoint
29-06 No-Flow Disable Timer
29-1* Deragging Function
29-10 Derag Cycles
29-11 Derag at Start/Stop
29-12 Deragging Run Time
29-13 Derag Speed [RPM]
29-14 Derag Speed [Hz]
29-15 Derag Off Delay
29-2* Derag Power Tuning
29-20 Derag Power[kW]
29-21 Derag Power[HP]
29-22 Derag Power Factor
29-23 Derag Power Delay
29-24 Low Speed [RPM]
29-25 Low Speed [Hz]
29-26 Low Speed Power [kW]
29-27 Low Speed Power [HP]
29-28 High Speed [RPM]
29-29 High Speed [Hz]
29-30 High Speed Power [kW]
29-31 High Speed Power [HP]
29-32 Derag On Ref Bandwidth
29-33 Power Derag Limit
29-34 Consecutive Derag Interval
29-4* Pre/Post Lube
29-40 Pre/Post Lube Function
29-41 Pre Lube Time
29-42 Post Lube Time
29-5* Flow Confirmation
29-50 Validation Time
29-51 Verification Time
MG20O702
Programming Guide
Default value 4-set-up
[0] Disabled 2 set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
0 s All set-ups
0.001 ProcessCtrlUnit All set-ups
0 ProcessCtrlUnit All set-ups
0 s All set-ups
ExpressionLimit 2 set-ups
[0] Off 1 set-up
0 s All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
10 s All set-ups
0 kW All set-ups
0 hp All set-ups
200 % All set-ups
601 s All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
5 % All set-ups
3 N/A 2 set-ups
ExpressionLimit All set-ups
[0] Disabled All set-ups
10 s All set-ups
10 s All set-ups
ExpressionLimit All set-ups
15 s All set-ups
