Parameter Description
26-35 Term. X42/5 High Ref./Feedb. Value
Range:
100
[-999999.999 -
*
999999.999 ]
3
3
26-36 Term. X42/5 Filter Time Constant
Range:
0.001 s
[0.001 -
*
10 s]
26-37 Term. X42/5 Live Zero
Option:
[0] Disabled
[1] Enabled
26-40 Terminal X42/7 Output
Option:
[0]
No operation
[100] Output freq.
0-100
[101] Reference Min-
Max
[102] Feedback
+-200%
[103] Motor cur. 0-
Imax
[104] Torque 0-Tlim
[105] Torque 0-Tnom
[106] Power 0-Pnom
[107] Speed 0-
HighLim
186
Function:
Enter the analog input scaling value
that corresponds to the high voltage
value set in parameter 26-21 Terminal
X42/3 High Voltage.
Function:
Enter the time constant. This is a first-
order digital low pass filter time constant
for suppressing noise in terminal X42/5. A
high time constant value improves
dampening but also increases the time
delay through the filter.
NOTICE
This parameter cannot be adjusted
while the motor is running.
Function:
This parameter makes it possible to enable the Live
Zero monitoring. E.g. where the analog input is a
of the frequency converter control, rather than
being used as of a decentral I/O system, such as a
Building Management System.
Function:
Set the function of terminal X42/7 as an
analog voltage output.
0-100 Hz, (0-20 mA)
Minimum reference - Maximum
reference, (0-20 mA)
-200% to +200% of
parameter 3-03 Maximum Reference, (0-20
mA)
0 - Inverter Max. Current
(parameter 16-37 Inv. Max. Current), (0-20
mA)
0 - Torque limit (parameter 4-16 Torque
Limit Motor Mode), (0-20 mA)
0 - Motor rated torque, (0-20 mA)
0 - Motor rated power, (0-20 mA)
0 - Speed High Limit
(parameter 4-13 Motor Speed High Limit
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Programming Guide
26-40 Terminal X42/7 Output
Option:
[108] Torque +-160%
[109] Out frq 0-Fmax
[113] Ext. Closed
Loop 1
[114] Ext. Closed
Loop 2
[115] Ext. Closed
Loop 3
[139] Bus ctrl.
[141] Bus ctrl t.o.
26-41 Terminal X42/7 Min. Scale
Range:
0 %
*
200 %]
26-42 Terminal X42/7 Max. Scale
Range:
100
%
200
*
%]
See principle graph for parameter 6-52 Terminal 42 Output
Max Scale.
26-43 Terminal X42/7 Bus Control
Range:
0 %
*
Function:
[RPM] and parameter 4-14 Motor Speed
High Limit [Hz]), (0-20 mA)
0-100%, (0-20 mA)
0-100%, (0-20 mA)
0-100%, (0-20 mA)
0-100%, (0-20 mA)
0-100%, (0-20 mA)
Function:
[0 -
Scale the minimum output of the selected analog
signal at terminal X42/7, as a percentage of the
maximum signal level. E.g. if a 0 V (or 0 Hz) is
desired at 25% of the maximum output value.
Then programme 25%. Scaling values up to 100%
can never be higher than the corresponding
setting in parameter 26-42 Terminal X42/7 Max.
Scale.
See principle graph for parameter 6-51 Terminal 42
Output Min Scale.
Function:
[0 -
Scale the maximum output of the selected analog
signal at terminal X42/7. Set the value to the
maximum value of the voltage signal output.
Scale the output to give a voltage lower than 10
V at full scale; or 10 V at an output below 100%
of the maximum signal value. If 10 V is the
desired output current at a value between
0-100% of the full-scale output, programme the
percentage value in the parameter, i.e. 50% = 10
V. If a voltage between 0 and 10 V is desired at
maximum output, calculate the percentage as
follows:
V
10
desired maximum voltage
i.e.
10
V
V :
5
× 100% = 200%
5
V
Function:
[0 - 100 %] Holds the level of terminal X42/7 if
controlled by bus.
x 100%
MG20O702
