Danfoss VLT AQUA Drive FC 202 Programming Manual page 65

Parameter Description
4-17 Torque Limit Generator Mode
Range: Function:
100 [ 0 - Enter the maximum torque limit for generator
% 1000.0 mode operation. The torque limit is active in
*
%] the speed range up to and including the rated
motor speed (parameter 1-25 Motor Nominal
Speed). Refer to parameter 14-25 Trip Delay at
Torque Limit for further details.
If a setting in parameter 1-00 Configuration
Mode to parameter 1-28 Motor Rotation Check is
changed, parameter 4-17 Torque Limit Generator
Mode is not automatically reset to the default
settings.
4-18 Current Limit
Range: Function:
Size [ 1.0 - Enter the current limit for motor and
related 1000.0 generator operation. To protect the motor
*
%] from reaching the stalling torque, the
default setting is 1.1 x the rated motor
torque (calculated value). If a setting in
parameter 1-00 Configuration Mode to 1-26
Motor Cont. Rated Torque is changed,
4-18 Current Limit is not automatically reset
to the default setting.
4-19 Max Output Frequency
Range: Function:
NOTICE
Size [ 1 -
related 590
*
This parameter cannot be adjusted
Hz]
while the motor is running.
Enter the maximum output frequency value.
Parameter 4-19 Max Output Frequency
specifies the absolute limit on the frequency
converter output frequency for improved
safety in applications where accidental
overspeeding must be avoided. This absolute
limit applies to all configurations and is
independent of the setting in
parameter 1-00 Configuration Mode.
NOTICE
When parameter 1-10 Motor Construction is set to [1] PM,
non-salient SPM, the maximum value is limited to 300 Hz
3.6.2 4-5* Adj. Warnings
Define adjustable warning limits for current, speed,
reference and feedback.
NOTICE
Not visible in display, only in MCT 10 Set-up Software.
MG20O702
Programming Guide
4-50 Warning Current Low
Range:
0 A [ 0 - par.
*
4-51 A]
4-51 Warning Current High
Range:
Size
related
*
4-52 Warning Speed Low
Range:
0 RPM
*
4-53 Warning Speed High
Range:
Size
related
*
NOTICE
Any changes in parameter 4-13 Motor Speed High Limit
[RPM] reset the value in parameter 4-53 Warning Speed
High to the same value as set in parameter 4-13 Motor
Speed High Limit [RPM].
If a different value is needed in parameter 4-53 Warning
Speed High, it must be set after programming of
parameter 4-13 Motor Speed High Limit [RPM]
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Function:
Enter the I value. When the motor current
LOW
falls below this limit (I
LOW
CURRENT LOW. The signal outputs can be
programmed to produce a status signal on
terminal 27 or 29 and on relay output 01 or 02.
Refer to Illustration 3.23.
Function:
[ par. Enter the I value. When the motor
HIGH
4-50 - par. current exceeds this limit (I
16-37 A]
display reads CURRENT HIGH. The signal
outputs can be programmed to produce
a status signal on terminal 27 or 29 and
on relay output 01 or 02. Refer to
Illustration 3.23.
Function:
[ 0 - Enter the n value. When the motor speed
LOW
par. 4-53 falls below this limit (n
RPM] SPEED LOW. The signal outputs can be
programmed to produce a status signal on
terminal 27 or 29 and on relay output 01 or
02. Programme the lower signal limit of the
motor speed, n , within the normal
LOW
working range of the frequency converter.
Refer to the Illustration 3.23.
Function:
[ par. Enter the n value. When the motor
HIGH
4-52 - speed exceeds this limit (n
par. 4-13
reads SPEED HIGH. The signal outputs can
RPM]
be programmed to produce a status signal
on terminal 27 or 29 and on relay output
01 or 02. Programme the upper signal limit
of the motor speed, n
normal working range of the frequency
converter. Refer to Illustration 3.23.
), the display reads
3
), the
HIGH
) the display reads
LOW
), the display
HIGH
, within the
HIGH
63
3
