Parameter Description
3.2.7 0-6* Password
0-60 Main Menu Password
Range:
100 [-9999 -
*
3 3
9999 ]
0-61 Access to Main Menu w/o Password
Option:
[0] Full access
[1] LCP: Read only Prevent unauthorized editing of Main Menu
[2] LCP: No access Prevent unauthorized viewing and editing of
[3] Bus: Read only
[4] Bus: No access
[5] All: Read only
[6] All: No access
If [0] Full access is selected, parameter 0-60 Main Menu
Password, parameter 0-65 Personal Menu Password and
parameter 0-66 Access to Personal Menu w/o Password are
ignored.
0-65 Personal Menu Password
Range:
200 [0 -
*
999 ]
0-66 Access to Personal Menu w/o Password
Option:
[0] Full access
[1] LCP: Read only Prevents unauthorized editing of My
[2] LCP: No access Prevents unauthorized viewing and editing
[3] Bus: Read only
[4] Bus: No access
[5] All: Read only
[6] All: No access
If parameter 0-61 Access to Main Menu w/o Password is set
to [0] Full access, this parameter is ignored.
36
Programming Guide
Function:
Define the password for access to the Main
Menu via the [Main Menu] key. If
parameter 0-61 Access to Main Menu w/o
Password is set to [0] Full access, this
parameter is ignored.
Function:
Disables password defined in
parameter 0-60 Main Menu Password.
parameters.
Main Menu parameters.
Function:
Define the password for access to the My
Personal Menu via the [Quick Menu] key. If
parameter 0-66 Access to Personal Menu w/o
Password is set to [0] Full access, this parameter
is ignored.
Function:
Disables password defined in
parameter 0-65 Personal Menu Password.
Personal Menu parameters.
of My Personal Menu parameters.
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
0-67 Bus Password Access
Range: Function:
0 [0 - 9999 ] Writing to this parameter enables users to
*
unlock the frequency converter from bus/MCT
10 Set-up Software.
3.2.8 0-7* Clock Settings
Set the time and date of the internal clock. The internal
clock can be used for e.g. timed actions, energy log, trend
analysis, date/time stamps on alarms, logged data and
preventive maintenance.
It is possible to program the clock for daylight saving time/
summertime, weekly working days/non-working days
including 20 exceptions (holidays etc.). Although the clock
settings can be set via the LCP, they can also be set along
with timed actions and preventative maintenance
functions using the MCT 10 Set-up Software software tool.
NOTICE
The frequency converter has no back-up of the clock
function and the set date/time resets to default
(2000-01-01 00:00) after a power down unless a Real
Time Clock module with back-up is installed. If no
module with back up is installed, it is recommended the
clock function is only used if the frequency converter is
integrated into an external system using serial communi-
cations, with the system maintaining synchronisation of
control equipment clock times. In parameter 0-79 Clock
Fault it is possible to program for a Warning in case
clock has not been set properly, e.g. after a power down.
NOTICE
When mounting an Analog I/O MCB 109 option card, a
battery back-up of the date and time is included.
0-70 Date and Time
Range: Function:
Size [ 0 - 0 ] Sets the date and time of the internal
related clock. The format to be used is set in
*
0-71 Date Format and parameter 0-72 Time
Format.
0-71 Date Format
Option: Function:
[0] YYYY-MM-DD Sets the date format to be used in the LCP.
[1] DD-MM-YYYY Sets the date format to be used in the LCP.
[2] MM/DD/YYYY Sets the date format to be used in the LCP.
