Parameter Description
23-01 ON Action
Arra [10]
Option: Function:
[27] Coast
[28] Freeze output
[29] Start timer 0
[30] Start timer 1
[31] Start timer 2
[32] Set digital out A low
[33] Set digital out B low
[34] Set digital out C low
[35] Set digital out D low
[36] Set digital out E low
[37] Set digital out F low
[38] Set digital out A high
[39] Set digital out B high
[40] Set digital out C high
[41] Set digital out D high
[42] Set digital out E high
[43] Set digital out F high
[60] Reset Counter A
[61] Reset Counter B
[70] Start Timer 3
[71] Start Timer 4
[72] Start Timer 5
[73] Start Timer 6
[74] Start Timer 7
[80] Sleep Mode
[81] Derag
NOTICE
For choices [32] - [43], see also parameter group 5-3*
Digital Outputs and 5-4* Relays.
23-02 OFF Time
Array [10]
Range: Function:
Size [ 0 - 0 ] Sets the OFF time for the timed action.
related
*
3.20.2 23-1* Maintenance
Wear and tear calls for periodic inspection and service of elements in the application, e.g. motor bearings, feedback sensors
and seals or filters. With preventive maintenance the service intervals may be programmed into the frequency converter.
The frequency converter gives a message when maintenance is required. 20 preventive maintenance events can be
programmed into the frequency converter. Specify the following for each event:
•
Maintenance item (e.g. "Motor Bearings")
•
Maintenance action (e.g. "Replace")
•
Maintenance Time Base (e.g. "Running Hours" or a specific date and time)
•
Maintenance Time Interval or the date and time of next maintenance
MG20O702
Programming Guide
23-02 OFF Time
Array [10]
Range:
23-03 OFF Action
Array [10]
See parameter 23-01 ON Action for available actions.
Option:
[0]
*
23-04 Occurrence
Array [10]
Option:
[0] All days
[1] Working days
[2] Non-working days
[3] Monday
[4] Tuesday
[5] Wednesday
[6] Thursday
[7] Friday
[8] Saturday
[9] Sunday
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Function:
NOTICE
The frequency converter has no
back-up of the clock function and
the set date/time is reset to default
(2000-01-01 00:00) after a power
down unless a Real Time Clock
module with back-up is installed. In
parameter 0-79 Clock Fault it is
possible to program for a Warning
in case clock has not been set
properly, e.g. after a power down.
Function:
Disabled
Function:
Select which day(s) the timed action
applies to. Specify working/non-working
days in parameter 0-81 Working Days,
parameter 0-82 Additional Working Days
and parameter 0-83 Additional Non-
Working Days.
3 3
