Parameters 23-** Time-Based Functions - Danfoss VLT AQUA Drive FC 202 Programming Manual

Parameter Description
3.20 Parameters 23-** Time-based
Functions
3.20.1 23-0* Timed Actions
3 3
Use Timed Actions for actions needing to be performed on
a daily or weekly basis, e.g. different references for working
hours/non-working hours. Up to 10 timed actions can be
programmed in the frequency converter. The timed action
number is selected from the list when entering parameter
group 23-0* Timed Actions from the LCP.
Parameter 23-00 ON Time – parameter 23-04 Occurrence
then refer to the selected timed action number. Each
timed action is divided into an ON time and an OFF time,
in which 2 different actions may be performed.
The clock control (parameter group 0-7* Clock Settings) of
Timed Actions can be overridden from Timed Actions Auto
(Clock Controlled) to Timed Actions Disabled, Constant OFF
Actions or Constant ON Actions either in 23-08 Timed
Actions Mode or with commands applied to the digital
inputs ([68] Timed Actions Disabled, [69] Constant OFF
Actions or [70] Constant ON Actions, in parameter group
5-1* Digital Inputs.
Display lines 2 and 3 in the LCP show the status for timed
actions mode (0-23 Display Line 2 Large and 0-24 Display
Line 3 Large, setting [1643] Timed Actions Status).
NOTICE
A change in mode via the digital inputs can only take
place if 23-08 Timed Actions Mode is set for [0] Times
Actions Auto.
If commands are applied simultaneously to the digital
inputs for Constant OFF and Constant ON, the timed
actions mode changes to timed actions auto and the 2
commands are disregarded.
If 0-70 Date and Time is not set or the frequency
converter is set to HAND or OFF mode (e.g. via the LCP),
the timed actions mode is changed to Timed Actions
Disabled.
The timed actions have a higher priority than the same
actions/commands activated by the digital inputs or the
Smart Logic Controller.
The actions programmed in timed actions are merged with
corresponding actions from digital inputs, control word via
bus and Smart Logic Controller, according to merge rules
set up in parameter group 8-5* Digital/Bus.
NOTICE
The clock (parameter group 0-7* Clock Settings) must be
correctly programmed for timed actions to function
correctly.
162
Programming Guide
NOTICE
When mounting an Analog I/O MCB 109 option card, a
battery back-up of the date and time is included.
NOTICE
The PC-based Configuration Tool MCT 10 Set-up
Software comprises a special guide for easy
programming of timed actions.
Size
related
[0]
[1]
[2]
[3]
[4]
[5]
[10] Select preset ref 0
[11] Select preset ref 1
[12] Select preset ref 2
[13] Select preset ref 3
[14] Select preset ref 4
[15] Select preset ref 5
[16] Select preset ref 6
[17] Select preset ref 7
[18] Select ramp 1
[19] Select ramp 2
[22] Run
[23] Run reverse
[24] Stop
[26] DC Brake
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
23-00 ON Time
Array [10]
Range: Function:
[ 0 - 0 ] Sets the ON time for the timed action.
NOTICE
*
The frequency converter has no
back-up of the clock function and
the set date/time resets to default
(2000-01-01 00:00) after a power
down unless a Real Time Clock
module with back-up is installed. In
parameter 0-79 Clock Fault it is
possible to program for a Warning
in case clock has not been set
properly, e.g. after a power down.
23-01 ON Action
Arra [10]
Option: Function:
Select the action during ON Time.
See parameter 13-52 SL Controller
Action for descriptions of the
options.
Disabled
No action
Select set-up 1
Select set-up 2
Select set-up 3
Select set-up 4
MG20O702
