Parameter Description

3.7 Parameters 5-** Digital In/Out

Parameter group for configuring the digital input and
output.
3.7.1 5-0* Digital I/O Mode
3 3
Parameters for configuring the input and output using
NPN and PNP.
5-00 Digital I/O Mode
Option:
[0] PNP - Active
at 24V
[1] NPN - Active
at 0V
5-01 Terminal 27 Mode
Option: Function:
NOTICE
This parameter cannot be adjusted while the
motor is running.
[0] Input Defines terminal 27 as a digital input.
[1] Output Defines terminal 27 as a digital output.
5-02 Terminal 29 Mode
Option: Function:
NOTICE
This parameter cannot be adjusted while the
motor is running.
[0] Input Defines terminal 29 as a digital input.
[1] Output Defines terminal 29 as a digital output.
3.7.2 5-1* Digital Inputs
Parameters for configuring the input functions for the
input terminals.
The digital inputs are used for selecting various functions
in the frequency converter. All digital inputs can be set to
the following functions:
66
Programming Guide
Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Digital inputs and programmed digital outputs
are pre-programmable for operation either in
PNP or NPN systems.
Action on positive directional pulses (0). PNP
systems are pulled down to GND.
Action on negative directional pulses (1). NPN
systems are pulled up to +24 V, internally in
the frequency converter.
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Options [120] - [138] are related to the Cascade Controller
functionality. For more information, see parameter group
25-** Cascade Controller.
