How to Programme

2.2.7 Quick Menu, Q3 Function Set-ups

The function set-up provides quick access to all parameters required for the majority of water and wastewater applications
including variable torque, constant torque, pumps, dosing pumps, well pumps, booster pumps, mixer pumps, aeration
blowers and other pump and fan applications. Amongst other features it also includes parameters for selecting which
variables to display on the LCP, digital preset speeds, scaling of analog references, closed loop single zone and multi-zone
applications and specific functions related to water and wastewater applications.
The Function Set-up parameters are grouped in the following way:
Q3-10 Clock Settings
Parameter 0-70 Date and Time
Parameter 0-71 Date Format
Parameter 0-72 Time Format
Parameter 0-74 DST/Summertime 0-23 Display Line 2 Large
Parameter 0-76 DST/Summertime
Start
Parameter 0-77 DST/Summertime
End
Table 2.2 Q3-1 General Settings
Q3-20 Digital Reference
Parameter 3-02 Minimum Reference
Parameter 3-03 Maximum Reference
Parameter 3-10 Preset Reference
5-13 Terminal 29 Digital Input
5-14 Terminal 32 Digital Input
5-15 Terminal 33 Digital Input
Table 2.3 Q3-2 Open Loop Settings
MG20O702
Programming Guide
Q3-1 General Settings
Q3-11 Display Settings
Parameter 0-20 Display Line 1.1
Small
0-21 Display Line 1.2 Small
0-22 Display Line 1.3 Small
0-24 Display Line 3 Large
Parameter 0-37 Display Text 1
Parameter 0-38 Display Text 2
Parameter 0-39 Display Text 3
Q3-2 Open Loop Settings
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
Q3-12 Analog Output
Parameter 6-50 Terminal 42 Output Relay
Parameter 6-51 Terminal 42 Output
Min Scale
Parameter 6-52 Terminal 42 Output
Max Scale
Q3-21 Analog Reference
Parameter 3-02 Minimum Reference
Parameter 3-03 Maximum Reference
Parameter 6-10 Terminal 53 Low Voltage
Parameter 6-11 Terminal 53 High Voltage
Parameter 6-14 Terminal 53 Low Ref./Feedb. Value
Parameter 6-15 Terminal 53 High Ref./Feedb. Value
Q3-13 Relays
1⇒Parameter 5-40 Function
Relay
Relay
2⇒Parameter 5-40 Function
Relay
Option relay
7⇒Parameter 5-40 Function
Relay
Option relay
8⇒Parameter 5-40 Function
Relay
Option relay
9⇒Parameter 5-40 Function
Relay
