Parameter Description
18-33 Analog Out X42/7 [V]
Range:
0 [0 - 30 ] Read-out of the value of the signal applied to
*
3 3
18-34 Analog Out X42/9 [V]
Range:
0 [0 - 30 ] Read-out of the value of the signal applied to
*
18-35 Analog Out X42/11 [V]
Range:
0 [0 - 30 ] Read-out of the value of the signal applied to
*
18-36 Analog Input X48/2 [mA]
Range:
0 [-20 - 20 ] View the actual current measured at input
*
18-37 Temp. Input X48/4
Range:
0 [-500 -
*
500 ]
18-38 Temp. Input X48/7
Range:
0 [-500 -
*
500 ]
18-39 Temp. Input X48/10
Range:
0 [-500 -
*
500 ]
132
Programming Guide
Function:
terminal X42/7 on the Analog I/O Card (MCB 109).
The value shown reflects the selection in
parameter 26-40 Terminal X42/7 Output.
Function:
terminal X42/9 on the Analog I/O Card (MCB 109).
The value shown reflects the selection in
parameter 26-50 Terminal X42/9 Output.
Function:
terminal X42/11 on the Analog I/O Card (MCB
109).
The value shown reflects the selection in
parameter 26-60 Terminal X42/11 Output.
Function:
X48/2 (MCB 114).
Function:
View the actual temperature measured at input
X48/4 (MCB 114). The temperature unit is
based on the selection in
parameter 35-00 Term. X48/4 Temperature Unit.
Function:
View the actual temperature measured at input
X48/7 (MCB 114). The temperature unit is
based on the selection in
parameter 35-02 Term. X48/7 Temperature Unit.
Function:
View the actual temperature measured at input
X48/10 (MCB 114). The temperature unit is
based on the selection in
parameter 35-04 Term. X48/10 Temperature Unit.
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
3.16.3 18-6* Inputs & Outputs 2
18-60 Digital Input 2
Range: Function:
0 [0 - 65535 ] View the signal states from the active digital
*
inputs on the MCO 102 (Advanced Cascade
Controller): Counting from right to left the
positions in the binary are: DI7...DI1 ⇒ pos.
2 ...pos. 8.
