Parameter Description
10-11 Process Data Config Write
Option:
[411] Motor Speed Low Limit [RPM]
[412] Motor Speed Low Limit [Hz]
[413] Motor Speed High Limit [RPM]
[414] Motor Speed High Limit [Hz]
[416] Torque Limit Motor Mode
[417] Torque Limit Generator Mode
[590] Digital & Relay Bus Control
[593] Pulse Out #27 Bus Control
[595] Pulse Out #29 Bus Control
[597] Pulse Out #X30/6 Bus Control
[653] Terminal 42 Output Bus Control
[663] Terminal X30/8 Output Bus Control
[673] Terminal X45/1 Bus Control
[683] Terminal X45/3 Bus Control
[890] Bus Jog 1 Speed
[891] Bus Jog 2 Speed
[894] Bus Feedback 1
[895] Bus Feedback 2
[896] Bus Feedback 3
[1680] Fieldbus CTW 1
[1682] Fieldbus REF 1
[1685] FC Port CTW 1
[1686] FC Port REF 1
10-12 Process Data Config Read
Option: Function:
Select the process read data for I/O Assembly Instances
101/151. Elements [2] and [3] of this array can be
selected. Elements [0] and [1] of the array are fixed.
10-13 Warning Parameter
Range: Function:
0 [0 - 65535 ] View a DeviceNet-specific Warning word. One
*
bit is assigned to every warning. Refer to the
DeviceNet Operating Instructions (MG33D) for
further information.
MG20O702
Programming Guide
Bit
0
Function:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Table 3.16 Warning Bits
10-14 Net Reference
Read only from LCP
Option: Function:
[0] Off Enables reference via analog/digital inputs.
[1] On
10-15 Net Control
Read only from LCP
Option: Function:
[0] Off
[1] On
3.11.3 10-2* COS Filters
10-20 COS Filter 1
Range:
0
*
65535 ]
10-21 COS Filter 2
Range:
0
*
65535 ]
