5-10 Terminal 18 Digital Input
The parameter contains all options and functions listed in
parameter group chapter 3.7.2 5-1* Digital Inputs except for
option [32] Pulse input.
5-11 Terminal 19 Digital Input
The parameter contains all options and functions listed in
parameter group chapter 3.7.2 5-1* Digital Inputs except for
option [32] Pulse input.
5-12 Terminal 27 Digital Input
The parameter contains all options and functions listed in
parameter group chapter 3.7.2 5-1* Digital Inputs except for
option [32] Pulse input.
5-13 Terminal 29 Digital Input
The parameter contains all options and functions listed in
parameter group chapter 3.7.2 5-1* Digital Inputs.
5-14 Terminal 32 Digital Input
The parameter contains all options and functions listed in
parameter group chapter 3.7.2 5-1* Digital Inputs except for
option [32] Pulse input.
5-15 Terminal 33 Digital Input
The parameter contains all options and functions listed in
parameter group chapter 3.7.2 5-1* Digital Inputs.
70
Programming Guide
Setting in Setting in
parameter parameter 25-06 Number of
group 5-1* Pumps
[0] No
[130] Pump1 Controlled by Frequency
Interlock RELAY1 Converter
(only if not controlled
lead pump) (cannot be
interlocked)
[131] Pump2 Controlled by Controlled by
Interlock RELAY2
[132] Pump3 Controlled by Controlled by
Interlock RELAY3
[133] Pump4 Controlled by Controlled by
Interlock RELAY4
[134] Pump5 Controlled by Controlled by
Interlock RELAY5
[135] Pump6 Controlled by Controlled by
Interlock RELAY6
[136] Pump7 Controlled by Controlled by
Interlock RELAY7
[137] Pump8 Controlled by Controlled by
Interlock RELAY8
[138] Pump9 Controlled by Controlled by
Interlock RELAY9
Danfoss A/S © Rev. 2014-01-21 All rights reserved.
5-16 Terminal X30/2 Digital Input
Option:
[0] No operation This parameter is active when option module
*
[1] Yes
5-17 Terminal X30/3 Digital Input
RELAY1
Option:
[0] No operation This parameter is active when option module
*
RELAY2
RELAY3
RELAY4
5-18 Terminal X30/4 Digital Input
RELAY5
Option:
RELAY6
[0] No operation This parameter is active when option module
*
RELAY7
RELAY8
5-20 Terminal X46/1 Digital Input
This parameter is related to the digital input on relay card MCB
113. The parameter contains all options and functions listed in
parameter group chapter 3.7.2 5-1* Digital Inputs except for
option [32] Pulse input.
5-21 Terminal X46/3 Digital Input
This parameter is related to the digital input on relay card MCB
113. The parameter contains all options and functions listed in
parameter group chapter 3.7.2 5-1* Digital Inputs except for
option [32] Pulse input.
5-22 Terminal X46/5 Digital Input
This parameter is related to the digital input on relay card MCB
113. The parameter contains all options and functions listed in
parameter group chapter 3.7.2 5-1* Digital Inputs except for
option [32] Pulse input.
5-23 Terminal X46/7 Digital Input
This parameter is related to the digital input on relay card MCB
113. The parameter contains all options and functions listed in
parameter group chapter 3.7.2 5-1* Digital Inputs except for
option [32] Pulse input.
5-24 Terminal X46/9 Digital Input
This parameter is related to the digital input on relay card MCB
113. The parameter contains all options and functions listed in
parameter group chapter 3.7.2 5-1* Digital Inputs except for
option [32] Pulse input.
Function:
MCB 101 is installed in the frequency
converter. The parameter contains all options
and functions listed in parameter group
chapter 3.7.2 5-1* Digital Inputs except for
option [32] Pulse input.
Function:
MCB 101 is installed in the frequency
converter. The parameter contains all options
and functions listed in parameter group
chapter 3.7.2 5-1* Digital Inputs except for
option [32] Pulse input.
Function:
MCB 101 is installed in the frequency
converter. The parameter contains all options
and functions listed in parameter group
chapter 3.7.2 5-1* Digital Inputs except for
option [32] Pulse input.
