Parameter Description

3 Parameter Description

3.1 Parameter Selection

The parameters are grouped into various parameter groups for easy selection of the correct parameter for optimised
frequency converter operation.
Overview of parameter groups
Group Title
0-** Operation/Display
1-** Load/Motor
2-** Brakes
3-** Reference/Ramps
4-** Limits/Warnings
5-** Digital In/Out
6-** Analog In/Out
8-** Communication and Options
9-** Profibus
10-** DeviceNet Fieldbus
13-** Smart Logic
14-** Special Functions
15-** Drive Information
16-** Data Readouts
18-** Info and Readouts
20-** Drive Closed Loop
21-** Extended Closed Loop
22-** Application Functions
23-** Time-based Functions
24-** Application Functions 2
25-** Basic Cascade Controller Functions
26-** Analog I/0 Option MCB 109
27-** Extended Cascade Control
29-** Water Application Functions
30-** Special Features
31-** Bypass Option
35-** Sensor Input Option
Table 3.1 Parameter Groups
Parameter descriptions and selections are displayed on the graphic (GLCP) or numeric (NLCP) in the display area. (See
chapter 2 How to Programme for details.) Access the parameters by pressing the [Quick Menu] or [Main Menu] key on the
control panel. The quick menu is used primarily for commissioning the unit at start-up by providing those parameters
necessary to start operation. The main menu provides access to all parameters for detailed application programming.
All digital input/output and analog input/output terminals are multifunctional. All terminals have factory default functions
suitable for the majority of water applications but if other special functions are required, they must be programmed in
parameter group 5-** Digital In/out or 6-** Analog In/out.
MG20O702
Programming Guide
Function
Parameters related to the fundamental functions of the frequency converter,
function of the LCP keys and configuration of the LCP display.
Parameter group for motor settings.
Parameter group for setting brake features in the frequency converter.
Parameters for reference handling, definitions of limitations, and configuration of
the reaction of the frequency converter to changes.
Parameter group for configuring limits and warnings.
Parameter group for configuring the digital inputs and outputs.
Parameter group for configuration of the analog inputs and outputs.
Parameter group for configuring communications and options.
Parameter group for Profibus-specific parameters (requires profibus option).
Parameter group for DeviceNet-specific parameters (requires DeviceNet option).
Parameter group for Smart Logic Control
Parameter group for configuring special frequency converter functions.
Parameter group containing frequency converter information such as operating
data, hardware configuration and software versions.
Parameter group for data read-outs, e.g. actual references, voltages, control, alarm,
warning and status words.
This parameter group contains the last 10 Preventive Maintenance logs.
This parameter group is used for configuring the closed loop PID Controller that
controls the output frequency of the unit.
Parameters for configuring the three Extended Closed Loop PID Controllers.
These parameters monitor water applications.
These parameters are for actions needed to be performed on a daily or weekly
basis, e.g. different references for working hours/non-working hours.
Parameters for the Drive Bypass.
Parameters for configuring the Basic Cascade Controller for sequence control of
multiple pumps.
Parameters for configuring the Analog I/0 Option MCB 109.
Parameters for configuring the Extended Cascade Control (MCO 101/MCO 102).
Parameters for setting water specific functions.
Parameters for configuring the brake resistor value.
Parameters for configuring the Bypass Option (MCO 104).
Parameters for configuring the Sensor Input Option (MCB 114)
